50KW250KWH Containerized Vanadium Redox Flow Battery Energy Storage System VRFB With BMS EMS PCS

50KW250KWH is a module containerized VRFB system
Availability:
Quantity:
Inquire Add to Basket

  • VRF-50

  • VCEC

NameTechnical Parameters
Battery TypeVanadium Redox Flow Battery
Rated Power50KW
Storage Capacity200KWh/300kWh/400kWh
Voltage Range104V~161.2V
Max Current500A
DOD%100%
CommunicationRS485/以太网
ProtocolModbus TCP/Modbus RTU
Ambient Temperature~-30℃——45℃
Protection GradeP54
Container Size(L*W*H)11.5mx2.438mx2.896m
WeightGross Weight 32T/41T/50T
OthersFor anti -corrosion design according to the application scenarios, or earthquake resistance design, etc.
