VRF-25
VCEC
性能参数 Performance Characteristics | ||
额定功率 Rated Power | kW | 25 |
额定电压 Rated Voltage | V | 60 |
电压范围 Voltage Range | V | 50~80 |
能量效率 Energy Efficiency | ＞75% | |
响应时间 Response Time | ms | < 5 |
工作周期 Duty Cycle | 100% | |
循环寿命 Cycle Life | cycle | >10000 |
物理参数 Physical Specifications | |
大小 (长 x 宽 x 高) Dimensions (Depth x Width x Height) | 955mm×990mm×720mm |
端口直径 Dia. | 32mm |
重量 Weight | 650kg |
装配 Mounting | 地面装配 Floor-mounted |
操作 Handling | 叉车或者吊车 Forklift or overhead crane |
环境限制–运行 Environmental Limits – Operating | |
操作温度范围 Service Temperature Range | -0°C ~ 45°C |
Max Working Pressure | 300kPa |
Max Positive and Negative Pressure Difference | 15kPa |
推荐流量 The Recommended Flow Rate | 5~6.5m3/h |
湿度 Humidity | 0% ~ 95%，non-condensing |
海拔高度 Altitude Range | 0m ~ 3000m |
环境限制 – 运输与存储 Environmental Limits – Shipping and Storage | |
操作温度范围 Service Temperature Range | -31°C ~ 70°C |
湿度 Humidity | 0% ~ 95%，non-condensing |
海拔高度 Altitude Range | 0m ~ 3000m |
