5KW20KWH Residential VRFB ESS Output 3 phases 380Vac

Rated Power

5kW

Rated Time

6hrs

Rated Energy

30kWh

Rated Capacity

630Ah

Rated Energy Efficiency

80 %

Maximum Power

20kW

Stack Weight

130kg

Stack Size

63cm×75cm×35cm

Battery Weight

2.5t

Battery Size

2.0m×1.2m×2.0m

Electrolyte Weight

2.2t

Electrolyte Volume

1.6m³

Electrolyte

1.5M V(IV/III）

Working Temperature

-30~60℃

Charging Voltage Limit

60VDC

Discharging Voltage Limit

40VDC

Cycle Life

20000 Times

Storage Life

Limitless
